52" Marston Pterodactyl - NEW revision March 2008!
twin engine, aileron, elevator, rudder and throttle
complete laser cut kit includes plans and 2 carbon spars
Design Notes:
The 52" span Marston Pterodactyl is the fifth evolution of the twin electric Pterodactyl, and the most advanced, benefiting from years of prior design heritage. It is the product of countless hours of research, brainstorming, and lots of building and re-building. Unlike the 80" model, this kit can be built in a few weeks and includes everything except covering material, hardware, and electronics. All wood required is included as well as two full length carbon spars and full size rolled plans. One-piece wing attaches to body with two nylon screws. Same beautiful organic lines as the 80" Pterodactyl, but considerably more complete and less complicated to build.
Intermediate level building skills are recommended.
Requires two small outrunner brushless motors (Axi/Atlas 2208 or equal), one 25A or two 10A controllers, four mini servos and a 2000 mah 3s Li-poly.
Wingspan 52 1/8”
Length 31”
wing area 330 square inches - 2.29 square feet
weight RTF 24 oz.
wing loading 10.7 oz/square foot
52" Pterodactyl flight pictures
More 52" Pterodactyl pictures
Video of 52" Pterodactyl- QuickTime 2.1 MB
Download the Building Instructions PDF
|
|
| Laser Cut 52" Kit Includes: |
Full sized rolled plans (36" x 65" 3-view, high quality plans suitable for building on), 14 laser cut sheets of balsa and lite-ply, two full span carbon fiber tubes and building instructions. All wood and carbon required is included. |
| Payment Notes: |
Payment is made securely through PayPal. Clicking on the Buy Now button takes you to their secure site. Payment can be made with a PayPal account or with a credit card. Email for other payment options. |
| Shipping: |
Shipping in the continental USA is $18.00. Please email for additional shipping charges outside of the USA. |
|
|
|
80" Marston Pterodactyl - short kit
twin engine, full house control (aileron, elevator, rudder, flaps, throttle)
weight RTF - 68 oz. with 3s2p 2600 mah Li-poly batteries
Design Notes:
The 80" span Marston Pterodactyl is the largest Pterodactyl. This is the fourth electric twin motor version of the Pterodactyl. The wing has very few straight surfaces, and is very strong. It utilizes a fully shear-webbed D-tube design with carbon reinforced spruce spars. The leading edge is 1/8" plywood, sheeted with 1/16" balsa. Airfoil is a modified 10% Clark Y. The high aspect ratio gives it excellent glide capability. The two-piece wing uses a 3/8" x 10" carbon wing joiner in a brass tube. The body uses carbon tube longerons that run from the base of the neck to the back of the tails. Short kit does not include spruce spars, balsa sheeting or carbon parts. Download parts list (below) for list of materials needed.
Advanced building skills are strongly recommended.
|
RCGroups Build Log of the Pterodactyl
More 80" Pterodactyl Pictures
Build Pictures
Video of First Launch - MPEG 3.3MB
Really short flight video - Quicktime 576K - MPEG4 556K
Flight at Visalia 2005 - Quicktime 2.5 MB - MPEG4 2.8 MB
Download the Parts List/Build Instructions PDF
|
| |
|
|
Rolled Plans $60
Two sheets. Includes building instructions.
See description below. |
|
|
| Laser Cut 80" Short Kit Includes: |
2 plans, 11 laser cut pieces of wood stock (two 6" x 24" sheets of 1/16" ply, four 6" x 24" sheet of 1/8" ply, three 6" x 24" sheet of 3/32" balsa, and two 6" x 24" sheets of 1/4" balsa), and building instructions. All ribs and ply pieces required are supplied. Some balsa parts will need to be cut by hand. This is a short kit, not all wood and parts will be supplied, just those that would be really hard to cut out by hand. This is a "builders kit"; not recommended for beginners. |
| Plans Include: |
1 sheet: Full size (36" x 85") plans - 3 view high quality suitable for building on
1 sheet: Full size parts printout (30" x 50") arranged in seven 6" x 24" blocks
(for transferring to 12 balsa and ply sheets) |
| Payment Notes: |
Payment is made securely through PayPal. Clicking on one of the Buy Now buttons takes you to their secure site. Payment can be made with a PayPal account or with a credit card. Email for other payment options. |
| Shipping: |
Shipping in the continental USA is $18.00. Please email for additional shipping charges outside of the USA. |
|
|
|
|
60" Pterodactyl - 3rd version - 2004
twin engine - speed 480 brushed motors
aileron, elevator, rudder, throttle
speaker/amp with screeching hawk sound controlled by transmitter
weight RTF - 42 oz. with 8 cell 1700 mah ni-cad battery |
42" Pterodactyl - 2nd version - 2000
twin engine - speed 280 brushed motors
aileron, elevator, rudder, throttle
weight RTF - 18 oz. with 8 cell 600 mah ni-cad battery |
31" Pterodactyl - 1st version - 1998
4 motors
elevons, throttle
weight RTF - 7 oz. with 6 cell 300 mah ni-cad battery
|
|
